Atos RZMO Series Proportional Relief Valve | RZMO-P3 RZMO-BEBP RZMO-REB | Hydraulic Pressure Control

Chengyuan Hydraulic presents the RZMO Series proportional pressure relief valves, expertly engineered as high-performance replacements for Atos (Italy) standards. This range covers direct-acting proportional control components, including base models and advanced versions with integrated digital amplifiers such as RZMO-P3-010, RZMO-BEBP-NP, and RZMO-REB-P-NP. As a vital component for stepless pressure regulation, Chengyuan ensures 100% Drop-in Interchangeability regarding mounting patterns (ISO 4401 compliant) and electrical connectivity. By optimizing the linear thrust of the solenoid and the vibration-damping structure of the spool, coupled with our 100% Simulation Load Testing, we guarantee exceptional pressure repeatability and minimal hysteresis under complex dynamic loads. This makes the RZMO series an ideal choice for injection molding, die-casting, and heavy-duty industrial control systems.

Technical Specifications

• Series Category: RZMO Series (Direct-acting)

• Nominal Size: Size 06 (ISO 4401-03)

• Max Operating Pressure: 210 bar / 315 bar (model dependent)

• Max Flow Rate: Up to 4 L/min (Standard) / 12 L/min (High flow options)

• Control Signal: 0-10V DC / 4-20mA (for models with integrated amplifiers)

• Hysteresis: ≤ 1.5% (with digital amplifier)

• Repeatability: ≤ ±1%

• Supply Voltage: 24V DC

• Seal Materials: NBR (Standard) / FKM (Optional)

• Protection Class: IP67 (for integrated electronics)

Key Technical Advantages:

• Integrated Digital Electronics (E-RI): Models such as REB and BEBP feature built-in digital amplifiers with high-speed processors, allowing software-based parameter tuning. This simplifies wiring and enhances anti-interference and dynamic response.

• Optimized Proportional Solenoid: Featuring a wet-armature solenoid with a friction-reducing coated armature. This ensures an excellent linear relationship between input current and output pressure, minimizing control errors.

• Precision-Lapped Spool: The spool is crafted from high-strength alloy steel and precision-lapped. Its specialized damping orifice design absorbs hydraulic pulsations, preventing high-frequency squealing during pressure adjustment.

• Superior Pressure Stability: These valves maintain highly stable set pressures even under fluctuating input flow conditions, ensuring consistent system performance.

Application Areas:

• Plastic Machinery: Holding pressure control and mold protection in injection molding machines.

• Die-Casting Equipment: Proportional regulation of injection pressure and system main pressure.

• Test Rigs: Precise load simulation for hydraulic component fatigue testing.

• General Industry: Tension control for winding machines and safety relief systems for hydraulic presses.

Expert Maintenance Tips:

• Electrical Connectivity: For models with integrated amplifiers, always connect or disconnect the 7-pin or 12-pin plugs while the power is OFF to prevent damage to the electronic modules.

• Fluid Cleanliness: Proportional valves are extremely sensitive to contamination. We recommend system filtration of at least 10μm to maintain cleanliness at ISO 4406 18/16/13 or better.

• Air Bleeding: After installation, use the air bleed screw on top of the solenoid to exhaust trapped air. Air bubbles can cause pressure instability and sluggish response times.
