Sun Hydraulics ZNKF Series Check Valve | ZNKF04021201 ZNKF03020401 | Cartridge Counterbalance Valve

The ZNKF Series threaded cartridge valves from Chengyuan Hydraulic are precision hydraulic control components fully compatible with Sun Hydraulics industrial standards. This range includes check valves and counterbalance valves widely used for load holding and directional control in mobile and industrial systems. The ZNKF series utilizes Sun’s iconic floating construction, which allows the internal components to self-center within the cavity. This significantly reduces the risk of sticking caused by over-torquing or cavity machining inaccuracies. Every valve (e.g., ZNKF03020401) undergoes 100% simulated full-load condition testing before shipping to ensure cracking pressures and leakage levels meet OEM standards, guaranteeing 100% original-place interchangeability.

Technical Specifications :

• Model Range: ZNKF04021201, ZNKF03020401

• Cavity Compatibility: Fits Sun T-11A / T-2A cavities

• Maximum Operating Pressure: 350 bar (35 MPa)

• Cracking Pressures: 0.3 bar, 1 bar, 2 bar (specification dependent)

• Rated Flow Rates: 30 L/min to 120 L/min (depending on frame size)

• Maximum Internal Leakage: 0.07 cm³/min (approx. 5 drops/min)

• Materials: High-hardness alloy steel spool with hardened and quenched sleeve

• Surface Treatment: Eco-friendly zinc plating or phosphating for enhanced corrosion resistance

Key Technical Advantages:

• Patented Floating Construction: The ZNKF series adopts Sun’s unique floating cartridge design. This ensures that internal working parts are not compressed by microscopic cavity deformation during tightening, preventing spool binding and enhancing reliability in complex operations.

• Excellent Contamination Resistance: Internal flow paths are optimized via CFD simulation. Paired with a large-stroke poppet design, the valve is insensitive to fine particulates in the oil, reducing seat scratching and extending service life in harsh environments like construction and mining.

• High-Pressure Leak-Free Sealing: The spool and seat undergo precision ultrasonic grinding to achieve an exceptional mechanical fit. At the 350 bar rated pressure, internal leakage is far below industry standards, making it an ideal core for heavy-duty lifting load-holding circuits.

• Total Interchangeability & Easy Installation: Manufactured strictly to standard UNF threads and SAE cavity dimensions. Users can screw Chengyuan products directly into existing Sun manifolds without modifying pipes, drastically reducing downtime and maintenance costs.

Application Areas:

• Construction Machinery: Outrigger locking and boom-holding circuits for excavators and cranes.

• Mobile Equipment: Attachment control systems for agricultural tractors and forestry machinery.

• Industrial Presses: Accumulator safety shut-off and system pressure protection circuits.

Expert Maintenance Tips:

• Torque Management: Despite the floating design, we recommend using a torque wrench for installation (e.g., 45-50 Nm for T-11A). Insufficient torque causes external leaks, while excessive torque increases fatigue stress on the cavity.

• Seal Inspection: When reinstalling, always check the O-rings and backup rings at the base for cuts or nicks. Damaged seals must be replaced immediately to prevent high-pressure external leakage.

• System Bleeding: After installing a counterbalance valve, cycle the actuator several times under low pressure to purge air from the valve chamber. This prevents vibrations or “squealing” noises caused by trapped air.
